Quartz Crystals
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 TX1 2.0*1.6*0.5mm 16MHz-96MHz 4
2 TX2 2.5*2.0*0.55mm 12MHz-54MHz 4
3 TX3 3.2*2.5*0.7mm 8MHz-104MHz 4
4 TX5 5.0*3.2*0.9mm 8MHz-100MHz 4
5 TX7 7.0*5.0*1.1mm 6MHz-110MHz 4
6 TX8 1.6*1.2*0.35mm 20MHz-66MHz 4
7 TX9 1.2*1.0*0.33mm 32MHz-96MHz 4
8 TG5 5.0*3.2*1.2mm 8MHz-80MHz 2
9 WX6 49S 3.2MHz-100MHz 2
10 WS6 49SS 3.2MHz-100MHz 2
11 WS7 49SS SMD 3.2MHz-100MHz 2
12 WX7 49SMD 3.2MHz-100MHz 2
13 WA2 2*6mm 4MHz-50MHz 2
14 WA3 3*8mm 4MHz-50MHz 2
Tuning Fork Crystal
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 TS7 1.2*1.0*0.5mm 32.768KHz 2
2 TS8 1.6*1.0*0.5mm 32.768KHz 2
3 TS9 2.0*1.2*0.6mm 32.768KHz 2
4 WX1 3.2*1.5*0.75mm 32.768KHz 2
5 WX3 3.8*8.0*2.5mm 30KHz-350KHz 4
6 WX4 6.9*4*1.3mm 32.768KHz 4
7 WX2 2*6mm 30KHz-350KHz 2
8 WT8 3*8mm 30KHz-350KHz 2
9 WA4 2*6mm/SMD 32.768KHz 2
10 WX8 2*6mm/SMD 30KHz-350KHz 2
Crystal Oscillator(CMOS)
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 TK2 2.5*2.0*0.81mm 32.768KHz 4
2 TK3 3.2*2.5*0.95mm 32.768KHz 4
3 TK4 2.5*2.0*0.81mm 32.768KHz Low Current Consumption 4
4 TK5 3.2*2.5*0.95mm 32.768KHz Low Current Consumption 4
5 TC1 2.05*1.65*0.75mm 1.5MHz-50MHz 4
6 TC2 2.5*2.0*0.81mm 1.25MHz-125MHz 4
7 TC3 3.2*2.5*0.95mm 1.25MHz-125MHz 4
8 TC5 5.0*3.2*1.2mm 13.7KHz-160MHz 4
9 TC7 7.0*5.0*1.3mm 13.7KHz-166MHz 4
10 TU2 2.5*2.0*0.81mm 1MHz-50MHz Ultra Low Power 4
11 TU3 3.2*2.5*0.95mm 1MHz-50MHz Ultra Low Power 4
12 TW2 2.5*2.0*0.81mm 1.25MHz-100MHz Extended Operating TemperatureRange 4
13 TW3 3.2*2.5*0.95mm 1.25MHz-100MHz Extended Operating TemperatureRange 4
14 TN2 2.5*2.0*0.81mm 20MHz-60MHz Ultra Low Noise 4
15 TN3 3.2*2.5*0.95mm 20MHz-60MHz Ultra Low Noise 4
16 LO1 20.8*12.46*5mm 0.25MHz-180MHz 4
17 LO2 12.46*12.46*5mm 0.25MHz-180MHz 4
FASTXO Crystal Oscillator(CMOS)
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 TB1 2.05*1.65*0.75mm 1MHz-200MHz 4
2 TB2 2.5*2.0*0.81mm 1MHz-200MHz 4
3 TB3 3.2*2.5*0.95mm 1MHz-200MHz 4
4 TB5 5.0*3.2*1.2mm 1MHz-200MHz 4
5 TB7 7.0*5.0*1.3mm 1MHz-200MHz 4
6 TL2 3.2*2.5*0.90mm 10MHz-250MHz Low Phase Jitter 6
7 TL4 5.0*3.2*1.25mm 10MHz-250MHz Low Phase Jitter 6
8 TL6 7.0*5.0*1.45mm 10MHz-250MHz Low Phase Jitter 6
Crystal Oscillator(LVPECL/LVDS/HCSL/CML)
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 TL3 3.2*2.5*0.90mm 10MHz-1500MHz 6
2 TL5 5.0*3.2*1.25mm 10MHz-1500MHz 6
3 TL7 7.0*5.0*1.45mm 10MHz-1500MHz 6
4 TP3 3.2*2.5*0.9mm 10MHz-250MHz Low Phase Jitter 6
5 TP5 5.0*3.2*1.25mm 10MHz-320MHz Low Phase Jitter 6
6 TP7 7.0*5.0*1.45mm 10MHz-320MHz Low Phase Jitter 6
7 TN7 7.0*5.0*1.45mm 70MHz-170MHz Ultra Low Phase Jitter 6
8 TQ7 7.0*5.0*1.45mm 25MHz-75MHz HCSL 6
VCXO
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 PV3 3.2*2.5*0.9mm 10MHz-250MHz 6
2 PV5 5.0*3.2*1.25mm 10MHz-250MHz 6
3 PV7 7.0*5.0*1.75mm 10MHz-250MHz 6
4 PL3 3.2*2.5*0.9mm 10MHz-1500MHz Differential Output 6
5 PL5 5.0*3.2*1.25mm 10MHz-1500MHz Differential Output 6
6 PL7 7.0*5.0*1.75mm 10MHz-1500MHz Differential Output 6
7 CL5 5.0*3.2*1.25mm 30MHz-250MHz Low Phase Jitter 6
8 CL7 7.0*5.0*1.75mm 1.5MHz-200MHz Low Phase Jitter 6
9 CV5 5.0*3.2*1.25mm 1.5MHz-170MHz Extended Operating TemperatureRange 6
10 CV7 7.0*5.0*1.75mm 1.5MHz-170MHz Extended Operating TemperatureRange 6
11 CV8 14.2*9.3*5.4mm 30MHz-250MHz 6
12 LV1 20.3*12.6*5.0mm or 12.6*12.6*5.0mm 1MHz-80MHz 4
13 LV2 13.9*9.1*3.6mm 50MHz-125MHz 4
TCXO/VC-TCXO
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 VC1 2.0*1.6*0.7mm 10MHz-52MHz 4/6
2 VC2 2.5*2.0*0.7mm 10MHz-52MHz 4
3 VC3 3.2*2.5*0.9mm 10MHz-52MHz 4
4 VC5 5.0*3.2*1.1mm 10MHz-52MHz 4
5 VC7 7.0*5.0*1.9mm 5MHz-52MHz 4
6 VC8 14.3*8.7*4.9mm 5MHz-40MHz 6
7 VP3 3.2*2.5*1.6mm 10MHz-1500MHz High Frequency TemperatureCompensated 6
8 VW5 5.0*3.2*1.55mm 10MHz-52MHz High Precision 4
9 VA7 7.0*5.0*1.9mm 5MHz-52MHz High Precision 4
10 VS7 7.0*5.0*1.9mm 5MHz-52MHz Stratum 3 4
11 VT7 7.0*5.0*1.9mm 10MHz-52MHz High Precision and High Temperature 4
12 VF2 20.4*12.8*7.8mm 10MHz-52MHz 4
13 WT1 18.5*12 mm to 91*56 mm 1MHz-1500MHz 4/5
OCXO
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 OC9 9.7*7.5*4.1mm 10MHz-40MHz 4
2 OC8 14.3*9.3*6.5mm 10MHz-40MHz 6
3 OCH 20.3*12.7*11.0mm 5MHz-40MHz 4
4 OCW 20.6*20.6*11.0mm 5MHz-40MHz 5
5 OSD 25.4*22.1*11.0mm 5MHz-40MHz 7
6 OLH 25.4*25.4*12.7mm 5MHz-40MHz 5
7 OCN 25.4*25.4*12.7mm 10MHz-40MHz Low Phase Noise, Low G-Sensitivity 5
8 OSH 36.3*27.2*12.7mm 5MHz-40MHz 5
9 OCD 36.3*27.2*12.7mm 10MHz DOCXO 5
Dielectric Ceramic Antenna
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 DA1 10*10mm to 35*35mm 1568 or 1575 or 1590MHz -
2 DA2 8*8mm to 25*25mm 1568 or 1575 or 1590MHz -
3 DA3 12*12mm to 25*25mm BDS-B1 or GPS-L1 -
4 DA4 43*37*13.6mm/61*61*18mm BDS-B1 or GPS-L1 -
5 DA5 6*5mm to 30*30mm 915MHz or 5810MHz -
SAW Resonators
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 SR1 2.0*1.6*1.0mm 154MHz-1000MHz 4
2 SR3 3.0*3.0*1.25mm 154MHz-10000MHz 6
3 SR4 3.8*3.8*1.5mm 154MHz-10000MHz 6
4 SR5 5.0*5.0*1.5mm 154MHz-10000MHz 8
5 SR6 5.0*3.5*1.4mm 154MHz-10000MHz 4
SAW Filters
PAGE SERIES DIMENSION(MM) FREQUENCY PAD PICTURE PDF
1 SF0 1.1*0.9*0.5mm 800MHz-2605MHz 5
2 SF1 1.4*1.1*0.6mm 800MHz-2605MHz 5
3 SF2 2.0*1.5*0.6mm 800MHz-2605MHz 4
4 SF3 3.0*3.0*1.25mm 300MHz-2605MHz 6
5 SF4 3.8*3.8*1.5mm 100MHz-1000MHz 6
6 SF5 5.0*5.0*1.5mm 100MHz-1000MHz 8
7 SW1 36*16*5.5mm 70MHz 6
8 SW2 34.8*12.6*5.5mm 50MHz-150MHz 6
9 SW3 27.2*12.6*7.0mm 70MHz-140MHz 6
10 SW4 22.5*17.5*7.5mm 70MHz 6
11 SW5 22.1*12.6*5.0mm 50MHz-150MHz 6
12 SW6 19.50*6.50*1.75mm 70MHz 10
13 SW7 14.5*10.0*5.1mm 140MHz 6
14 SW8 13.30*6.5*1.8mm 50MHz-150MHz 12
15 SW9 12.0*7.2*4.2mm 100MHz-1000MHz 4
