TX1 2.0*1.6mm SMD 16.000MHz 8pF ±10ppm quartz crystal
TX1.pdfSale
¥0.80
In Stock
Ladder Price
-
Free ShippingFor orders from ￥300
-
Support 24/7Call us anytime
-
100% SafetyOnly secure payments
-
Hot OffersDiscounts up to 20%
Series
TX1
Package/Case
SMD2016
Frequency
16.000000 MHz
CL
8 pF
Frequency Tolerance （25±3℃）
±10 ppm
Operating Temperature
-20+70 ℃
Frequency Stability vs.Temperature
±10 ppm
L x W/Size
2.0*1.6 mm
Height
0.5 mm
Overtone
Fundamental
E.S.R
80~200 Ω
Shunt Capacitance(C0)
3.0 pF
Storage Temperature
-55~+125 ℃
Drive Level
1~200(50 Typical μW
Aging
±3.0 ppm/year
Lead Quantity
4 Pin
Encapsulation technology
Seam Sealing
MPQ
3000 pcs
Package type
Tape/Reel
Mounting type
SMT
Pb Free
Yes
Application level
Consumer
Partlife Cycle Code
Active
Material
Seam sealed
Country of Origin
China
MFG
WTL International Limited
Special Requirement
No Special
Features
Size 2.0 × 1.6 , Ultra thin , thickness 0.5mm
High precision and high frequency stability
Excellent heat resistance and environmental characteristics
Designed for automatic mounting and reflow soldering
RoHS Compliant / Pb Free
